TECHNICAL DATA OF THE BMW X4.

Select model

Weight

Unladen weight EU in kg 1,875
Max. permissible weight in kg 2,420
Permitted load in kg 620
Permitted axle load front/rear in kg 1,160/1,400
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 215
Acceleration 0–100 km/h in s 8.4-8.3

Fuel consumption

Urban in l/100 km 8.8
Extra-urban in l/100 km 7.0
Combined in l/100 km 7.7
CO2 combined emissions in g/km 175
Tank capacity, approx. in l 65

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1,890
Max. permissible weight in kg 2,450
Permitted load in kg 635
Permitted axle load front/rear in kg 1,160/1,400
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 185 (252)/5,200-6,500
Engine torque (Nm) at 1/min 350/1,450-4,800
Compression ratio : 1 10.2

Performance

Top speed in km/h 242-235
Acceleration 0–100 km/h in s 8.3-6.4

Fuel consumption

Urban in l/100 km 9.0
Extra-urban in l/100 km 7.2
Combined in l/100 km 7.9
CO2 combined emissions in g/km 180
Tank capacity, approx. in l 65

Wheels

Tyre dimensions front 225/60 R18 104 W XL
Tyre dimensions rear 225/60 R18 104 W XL
Wheel dimensions and material front 7 J x 18 inches, light-alloy
Wheel dimensions and material rear 7 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1,995
Max. permissible weight in kg 2,500
Permitted load in kg 580
Permitted axle load front/rear in kg 1,220/1,425
Luggage capacity min. (seats up or roof down) in l 525
Luggage capacity max. (seats down or roof up) in l 1,430
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2.998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 285 (387)/5,800-6,500
Engine torque (Nm) at 1/min 500/1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4,9-4,5

Fuel consumption

Urban in l/100 km 11.2
Extra-urban in l/100 km 7.6
Combined in l/100 km 8.9
CO2 combined emissions in g/km 204
Tank capacity, approx. in l 65

Wheels

Tyre dimensions front 245/45 R20 103 W XL
Tyre dimensions rear 275/40 R20 106 W XL
Wheel dimensions and material front 8 J x 20 inches, light-alloy
Wheel dimensions and material rear 9.5 J x 20 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions of the BMW X4.

BMW X4 xDrive30i:
Fuel consumption in l/100 km (combined): 8.5–7.9
CO2 emissions in g/km (combined): 193–171

BMW X4 M40i:
Fuel consumption in l/100 km (combined): 9.5–8.7
CO2 emissions in g/km (combined): 216–198


Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more
​

Fuel consumption and CO2 emissions of the BMW X4.

  • BMW X4 xDrive30i:
    Fuel consumption in l/100 km (combined): 7.9
    CO2 emissions in g/km (combined): 180


    BMW X4 M40i:
    Fuel consumption in l/100 km (combined): 8.9
    CO2 emissions in g/km (combined): 204

    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
