BMW Z4 G29 2022 Thundernight technical data

THE Z4

BMW Z4 ROADSTER: ENGINES & TECHNICAL DATA.

THE Z4BMW Z4 ROADSTER: ENGINES & TECHNICAL DATA.
BMW Z4: Overview

The key facts and figures for the BMW Z4 Roadster at a glance:


  • Engine, consumption and CO2 emissions
  • Performance data such as displacement, hp, Nm and acceleration
  • Weight, dimensions, wheel and tyre sizes
Read more

BMW Z4 ROADSTER: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1,495-1,480 [1,505-1,495]
Max. permissible weight in kg 1,725 [1,740]
Permitted load in kg 305-320 [310-320]
Permitted axle load front/rear in kg 830/935 [830/935]
Luggage capacity min. (seats up or roof down) in l 281 [281]
Luggage capacity max. (seats down or roof up) in l 281 [281]
Trailer load (unbraked) in kg -
Trailer load 12% (braked) in kg -
Trailer load 8% (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 145 (197)/4,500-6,500
Engine torque (Nm) at 1/min 320/1,450-4,200
Compression ratio : 1 10.2

Performance

Top speed in km/h 241 [240]
Acceleration 0–100 km/h in s 6.8 [6.6]

Fuel consumption

Urban in l/100 km 9.3 [7.8]
Extra-urban in l/100 km 6.0 [5.7]
Combined in l/100 km 7.2 [6.5]
CO2 combined emissions in g/km 165 [148]
Tank capacity, approx. in l 52

Wheels

Tyre dimensions front 225/50 R17 94 W
Tyre dimensions rear 255/45 R17 98 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1.505
Max. permissible weight in kg 1,740
Permitted load in kg 310
Permitted axle load front/rear in kg 830/935
Luggage capacity min. (seats up or roof down) in l 281
Luggage capacity max. (seats down or roof up) in l 281
Trailer load (unbraked) in kg -
Trailer load 12% (braked) in kg -
Trailer load 8% (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 190 (258)/5,000-6,500
Engine torque (Nm) at 1/min 400/1,550-4,400
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.4

Fuel consumption

Urban in l/100 km 7.9
Extra-urban in l/100 km 5.7
Combined in l/100 km 6.5
CO2 combined emissions in g/km 149
Tank capacity, approx. in l 52

Wheels

Tyre dimensions front 225/50 R17 94 W
Tyre dimensions rear 255/45 R17 98 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,630-1,610
Max. permissible weight in kg 1,860
Permitted load in kg 305-325
Permitted axle load front/rear in kg 865/995
Luggage capacity min. (seats up or roof down) in l 281
Luggage capacity max. (seats down or roof up) in l 281
Trailer load (unbraked) in kg -
Trailer load 12% (braked) in kg -
Trailer load 8% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 250-285 (340-387)/5,000-6,500
Engine torque (Nm) at 1/min 500/1,600-5,000
Compression ratio : 1 11.0-10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.5-4.1

Fuel consumption

Urban in l/100 km 9.8
Extra-urban in l/100 km 6.2
Combined in l/100 km 7.5
CO2 combined emissions in g/km 171
Tank capacity, approx. in l 52

Wheels

Tyre dimensions front 255/40 ZR18 95 Y
Tyre dimensions rear 275/40 ZR18 99 Y
Wheel dimensions and material front 9 J x 18 inches, light-alloy
Wheel dimensions and material rear 10 J x 18 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.
​

Fuel consumption and CO2 emissions.

  • BMW Z4 Roadster M40i(1):
    Fuel consumption in l/100 km (combined): 7.5
    CO2 emissions in g/km (combined): 171

    (1)Values are preliminary

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.
    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
